多线程异步提高RK3588的NPU占用率，进而提高yolov5s帧率_rk3588 多线程_rknn多线程

print("总平均帧率\t", frames / (time.time() - initTime))
# 释放cap和rknn线程池
cap.release()
cv2.destroyAllWindows()
pool.release()
1
2
3
4
5

这是在不同线程数下视频推理的帧率:

测试模型来源 yolov5s，激活函数为silu（非relu优化版本）

resnet18_for_rk3588, resnet26, resnet50

测试视频为 新宝岛

resnet50在9线程下的NPU占用率:

可以看到此时NPU的性能发挥到近乎极致，其推理性能约为280帧

• yolov5s在6线程下NPU利用率仅有50 - 60%左右, 性能劣化原因猜想：
  1. python的GIL为伪多线程, 换为c++或许在8线程前仍有较大提升
  2. rk3588的CPU性能跟不上, 对OpenCV绘框部分做c++优化或许有提升

完整代码

可移步rknn多线程获取yolov5s, resnet26, resnet50的rknn模型、完整代码和演示视频

main.py

import cv2
import time
from rknnpool import rknnPoolExecutor
# 图像处理函数，实际应用过程中需要自行修改
from func import myFunc

cap = cv2.VideoCapture('./video/islandBenchmark.mp4')
# cap = cv2.VideoCapture(0)
modelPath = "./rknnModel/yolov5s.rknn"
# 线程数
TPEs = 6
# 初始化rknn池
pool = rknnPoolExecutor(
    rknnModel=modelPath,
    TPEs=TPEs,
    func=myFunc)

# 初始化异步所需要的帧
if (cap.isOpened()):
    for i in range(TPEs + 1):
        ret, frame = cap.read()
        if not ret:
            cap.release()
            del pool
            exit(-1)
        pool.put(frame)

frames, loopTime, initTime = 0, time.time(), time.time()
while (cap.isOpened()):
    frames += 1
    ret, frame = cap.read()
    if not ret:
        break
    pool.put(frame)
    frame, flag = pool.get()
    if flag == False:
        break
    cv2.imshow('test', frame)
    if cv2.waitKey(1) & 0xFF == ord('q'):
        break
    if frames % 30 == 0:
        print("30帧平均帧率:\t", 30 / (time.time() - loopTime), "帧")
        loopTime = time.time()

print("总平均帧率\t", frames / (time.time() - initTime))
# 释放cap和rknn线程池
cap.release()
cv2.destroyAllWindows()
pool.release()
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49

rknnpool.py

from queue import Queue
from rknnlite.api import RKNNLite
from concurrent.futures import ThreadPoolExecutor, as_completed


def initRKNN(rknnModel="./rknnModel/yolov5s.rknn", id=0):
    rknn_lite = RKNNLite()
    ret = rknn_lite.load_rknn(rknnModel)
    if ret != 0:
        print("Load RKNN rknnModel failed")
        exit(ret)
    if id == 0:
        ret = rknn_lite.init_runtime(core_mask=RKNNLite.NPU_CORE_0)
    elif id == 1:
        ret = rknn_lite.init_runtime(core_mask=RKNNLite.NPU_CORE_1)
    elif id == 2:
        ret = rknn_lite.init_runtime(core_mask=RKNNLite.NPU_CORE_2)
    elif id == -1:
        ret = rknn_lite.init_runtime(core_mask=RKNNLite.NPU_CORE_0_1_2)
    else:
        ret = rknn_lite.init_runtime()
    if ret != 0:
        print("Init runtime environment failed")
        exit(ret)
    print(rknnModel, "\t\tdone")
    return rknn_lite


def initRKNNs(rknnModel="./rknnModel/yolov5s.rknn", TPEs=1):
    rknn_list = []
    for i in range(TPEs):
        rknn_list.append(initRKNN(rknnModel, i % 3))
    return rknn_list


class rknnPoolExecutor():
    def __init__(self, rknnModel, TPEs, func):
        self.TPEs = TPEs
        self.queue = Queue()
        self.rknnPool = initRKNNs(rknnModel, TPEs)
        self.pool = ThreadPoolExecutor(max_workers=TPEs)
        self.func = func
        self.num = 0

    def put(self, frame):
        self.queue.put(self.pool.submit(
            self.func, self.rknnPool[self.num % self.TPEs], frame))
        self.num += 1

    def get(self):
        if self.queue.empty():
            return None, False
        temp = []
        temp.append(self.queue.get())
        for frame in as_completed(temp):
            return frame.result(), True

    def release(self):
        self.pool.shutdown()
        for rknn_lite in self.rknnPool:
            rknn_lite.release()
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61

func.py

#以下代码改自https://github.com/rockchip-linux/rknn-toolkit2/tree/master/examples/onnx/yolov5
import cv2
import numpy as np
from rknnlite.api import RKNNLite

QUANTIZE_ON = True

OBJ_THRESH, NMS_THRESH, IMG_SIZE = 0.25, 0.45, 640

CLASSES = ("person", "bicycle", "car", "motorbike ", "aeroplane ", "bus ", "train", "truck ", "boat", "traffic light",
           "fire hydrant", "stop sign ", "parking meter", "bench", "bird", "cat", "dog ", "horse ", "sheep", "cow", "elephant",
           "bear", "zebra ", "giraffe", "backpack", "umbrella", "handbag", "tie", "suitcase", "frisbee", "skis", "snowboard", "sports ball", "kite",
           "baseball bat", "baseball glove", "skateboard", "surfboard", "tennis racket", "bottle", "wine glass", "cup", "fork", "knife ",
           "spoon", "bowl", "banana", "apple", "sandwich", "orange", "broccoli", "carrot", "hot dog", "pizza ", "donut", "cake", "chair", "sofa",
           "pottedplant", "bed", "diningtable", "toilet ", "tvmonitor", "laptop	", "mouse	", "remote ", "keyboard ", "cell phone", "microwave ",
           "oven ", "toaster", "sink", "refrigerator ", "book", "clock", "vase", "scissors ", "teddy bear ", "hair drier", "toothbrush ")


def sigmoid(x):
    return 1 / (1 + np.exp(-x))


def xywh2xyxy(x):
    # Convert [x, y, w, h] to [x1, y1, x2, y2]
    y = np.copy(x)
    y[:, 0] = x[:, 0] - x[:, 2] / 2  # top left x
    y[:, 1] = x[:, 1] - x[:, 3] / 2  # top left y
    y[:, 2] = x[:, 0] + x[:, 2] / 2  # bottom right x
    y[:, 3] = x[:, 1] + x[:, 3] / 2  # bottom right y
    return y


def process(input, mask, anchors):

    anchors = [anchors[i] for i in mask]
    grid_h, grid_w = map(int, input.shape[0:2])

    box_confidence = sigmoid(input[..., 4])
    box_confidence = np.expand_dims(box_confidence, axis=-1)

    box_class_probs = sigmoid(input[..., 5:])

    box_xy = sigmoid(input[..., :2])*2 - 0.5

    col = np.tile(np.arange(0, grid_w), grid_w).reshape(-1, grid_w)
    row = np.tile(np.arange(0, grid_h).reshape(-1, 1), grid_h)
    col = col.reshape(grid_h, grid_w, 1, 1).repeat(3, axis=-2)
    row = row.reshape(grid_h, grid_w, 1, 1).repeat(3, axis=-2)
    grid = np.concatenate((col, row), axis=-1)
    box_xy += grid
    box_xy *= int(IMG_SIZE/grid_h)

    box_wh = pow(sigmoid(input[..., 2:4])*2, 2)
    box_wh = box_wh * anchors

    box = np.concatenate((box_xy, box_wh), axis=-1)

    return box, box_confidence, box_class_probs


def filter_boxes(boxes, box_confidences, box_class_probs):
    """Filter boxes with box threshold. It's a bit different with origin yolov5 post process!

    # Arguments
        boxes: ndarray, boxes of objects.
        box_confidences: ndarray, confidences of objects.
        box_class_probs: ndarray, class_probs of objects.

    # Returns
        boxes: ndarray, filtered boxes.
        classes: ndarray, classes for boxes.
        scores: ndarray, scores for boxes.
    """
    boxes = boxes.reshape(-1, 4)
    box_confidences = box_confidences.reshape(-1)
    box_class_probs = box_class_probs.reshape(-1, box_class_probs.shape[-1])

    _box_pos = np.where(box_confidences >= OBJ_THRESH)
    boxes = boxes[_box_pos]
    box_confidences = box_confidences[_box_pos]
    box_class_probs = box_class_probs[_box_pos]

    class_max_score = np.max(box_class_probs, axis=-1)
    classes = np.argmax(box_class_probs, axis=-1)
    _class_pos = np.where(class_max_score >= OBJ_THRESH)

    boxes = boxes[_class_pos]
    classes = classes[_class_pos]
    scores = (class_max_score * box_confidences)[_class_pos]

    return boxes, classes, scores


def nms_boxes(boxes, scores):
    """Suppress non-maximal boxes.

    # Arguments
        boxes: ndarray, boxes of objects.
        scores: ndarray, scores of objects.

    # Returns
        keep: ndarray, index of effective boxes.
    """
    x = boxes[:, 0]
    y = boxes[:, 1]
    w = boxes[:, 2] - boxes[:, 0]
    h = boxes[:, 3] - boxes[:, 1]

    areas = w * h
    order = scores.argsort()[::-1]

    keep = []
    while order.size > 0:
        i = order[0]
        keep.append(i)

        xx1 = np.maximum(x[i], x[order[1:]])
        yy1 = np.maximum(y[i], y[order[1:]])
        xx2 = np.minimum(x[i] + w[i], x[order[1:]] + w[order[1:]])
        yy2 = np.minimum(y[i] + h[i], y[order[1:]] + h[order[1:]])

        w1 = np.maximum(0.0, xx2 - xx1 + 0.00001)
        h1 = np.maximum(0.0, yy2 - yy1 + 0.00001)
        inter = w1 * h1

        ovr = inter / (areas[i] + areas[order[1:]] - inter)
        inds = np.where(ovr <= NMS_THRESH)[0]
        order = order[inds + 1]
    keep = np.array(keep)
    return keep


def yolov5_post_process(input_data):
    masks = [[0, 1, 2], [3, 4, 5], [6, 7, 8]]
    anchors = [[10, 13], [16, 30], [33, 23], [30, 61], [62, 45],
               [59, 119], [116, 90], [156, 198], [373, 326]]

    boxes, classes, scores = [], [], []
    for input, mask in zip(input_data, masks):
        b, c, s = process(input, mask, anchors)
        b, c, s = filter_boxes(b, c, s)
        boxes.append(b)
        classes.append(c)
        scores.append(s)

    boxes = np.concatenate(boxes)
    boxes = xywh2xyxy(boxes)
    classes = np.concatenate(classes)
    scores = np.concatenate(scores)

    nboxes, nclasses, nscores = [], [], []
    for c in set(classes):
        inds = np.where(classes == c)
        b = boxes[inds]
        c = classes[inds]
        s = scores[inds]

        keep = nms_boxes(b, s)

        nboxes.append(b[keep])
        nclasses.append(c[keep])
        nscores.append(s[keep])

    if not nclasses and not nscores:
        return None, None, None

    boxes = np.concatenate(nboxes)
    classes = np.concatenate(nclasses)
    scores = np.concatenate(nscores)

    return boxes, classes, scores


def draw(image, boxes, scores, classes):
    for box, score, cl in zip(boxes, scores, classes):
        top, left, right, bottom = box
        # print('class: {}, score: {}'.format(CLASSES[cl], score))
        # print('box coordinate left,top,right,down: [{}, {}, {}, {}]'.format(top, left, right, bottom))
        top = int(top)
        left = int(left)
        right = int(right)
        bottom = int(bottom)

        cv2.rectangle(image, (top, left), (right, bottom), (255, 0, 0), 2)
        cv2.putText(image, '{0} {1:.2f}'.format(CLASSES[cl], score),
                    (top, left - 6),
                    cv2.FONT_HERSHEY_SIMPLEX,
                    0.6, (0, 0, 255), 2)


def letterbox(im, new_shape=(640, 640), color=(0, 0, 0)):
    shape = im.shape[:2]  # current shape [height, width]
    if isinstance(new_shape, int):
        new_shape = (new_shape, new_shape)

    r = min(new_shape[0] / shape[0], new_shape[1] / shape[1])

    ratio = r, r  # width, height ratios
    new_unpad = int(round(shape[1] * r)), int(round(shape[0] * r))
    dw, dh = new_shape[1] - new_unpad[0], new_shape[0] - \
        new_unpad[1]  # wh padding

    dw /= 2  # divide padding into 2 sides
    dh /= 2

 **自我介绍一下，小编13年上海交大毕业，曾经在小公司待过，也去过华为、OPPO等大厂，18年进入阿里一直到现在。**

**深知大多数Python工程师，想要提升技能，往往是自己摸索成长或者是报班学习，但对于培训机构动则几千的学费，着实压力不小。自己不成体系的自学效果低效又漫长，而且极易碰到天花板技术停滞不前！**

**因此收集整理了一份《2024年Python开发全套学习资料》，初衷也很简单，就是希望能够帮助到想自学提升又不知道该从何学起的朋友，同时减轻大家的负担。**

![img](https://img-blog.csdnimg.cn/img_convert/2c9592ecf9dee95097c0187861c256f9.png)

![img](https://img-blog.csdnimg.cn/img_convert/d927814b2dc0a2ffe09d6451dba8f3ec.png)

![img](https://img-blog.csdnimg.cn/img_convert/6f52fc3dab855a639a2c8e96eeb9158c.png)

![img](https://img-blog.csdnimg.cn/img_convert/82373c89c328391ed48a76254162cfb7.png)

![img](https://img-blog.csdnimg.cn/img_convert/6c361282296f86381401c05e862fe4e9.png)

![img](https://img-blog.csdnimg.cn/img_convert/9f49b566129f47b8a67243c1008edf79.png)

**既有适合小白学习的零基础资料，也有适合3年以上经验的小伙伴深入学习提升的进阶课程，基本涵盖了95%以上前端开发知识点，真正体系化！**

**由于文件比较大，这里只是将部分目录大纲截图出来，每个节点里面都包含大厂面经、学习笔记、源码讲义、实战项目、讲解视频，并且后续会持续更新**

**如果你觉得这些内容对你有帮助，可以扫码获取！！！（备注Python）**

[外链图片转存中...(img-TOQUxa54-1713209744916)]

![img](https://img-blog.csdnimg.cn/img_convert/6c361282296f86381401c05e862fe4e9.png)

![img](https://img-blog.csdnimg.cn/img_convert/9f49b566129f47b8a67243c1008edf79.png)

**既有适合小白学习的零基础资料，也有适合3年以上经验的小伙伴深入学习提升的进阶课程，基本涵盖了95%以上前端开发知识点，真正体系化！**

**由于文件比较大，这里只是将部分目录大纲截图出来，每个节点里面都包含大厂面经、学习笔记、源码讲义、实战项目、讲解视频，并且后续会持续更新**

**如果你觉得这些内容对你有帮助，可以扫码获取！！！（备注Python）**

<img src="https://img-community.csdnimg.cn/images/fd6ebf0d450a4dbea7428752dc7ffd34.jpg" alt="img" style="zoom:50%;" />
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
