用客户端连接Sqlserver，查看test库下的INFORMATION_SCHEMA.TABLES中是否出现TABLE_SCHEMA = cdc的表，如果出现，说明已经成功安装Sqlserver并启用了CDC。

1> use test;
2> go
Changed database context to 'test'.
1> select * from INFORMATION_SCHEMA.TABLES;
2> go

1
2
3
4
5
6

TABLE_CATALOG	TABLE_SCHEMA	TABLE_NAME	       TABLE_TYPE
test	            dbo	      user_info	         BASE TABLE
test	            dbo	      systranschemas	   BASE TABLE
test	            cdc	      change_tables	     BASE TABLE
test	            cdc	      ddl_history	       BASE TABLE
test	            cdc	      lsn_time_mapping	 BASE TABLE
test	            cdc	      captured_columns	 BASE TABLE
test	            cdc	      index_columns	     BASE TABLE
test	            dbo	      orders	           BASE TABLE
test	            cdc	      dbo_orders_CT	     BASE TABLE

1
2
3
4
5
6
7
8
9
10
11

二、具体实现

2.1 Flik-CDC采集SqlServer主程序

添加依赖包：

        <dependency>
            <groupId>com.ververica</groupId>
            <artifactId>flink-connector-sqlserver-cdc</artifactId>
            <version>3.0.0</version>
        </dependency>

1
2
3
4
5
6

编写主函数：

    public static void main(String[] args) throws Exception {

        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();

        // 设置全局并行度
        env.setParallelism(1);
        // 设置时间语义为ProcessingTime
        env.getConfig().setAutoWatermarkInterval(0);
        // 每隔60s启动一个检查点
        env.enableCheckpointing(60000, CheckpointingMode.EXACTLY\_ONCE);
        // checkpoint最小间隔
        env.getCheckpointConfig().setMinPauseBetweenCheckpoints(1000);
        // checkpoint超时时间
        env.getCheckpointConfig().setCheckpointTimeout(60000);
        // 同一时间只允许一个checkpoint
        // env.getCheckpointConfig().setMaxConcurrentCheckpoints(1);
        // Flink处理程序被cancel后，会保留Checkpoint数据
        // env.getCheckpointConfig().setExternalizedCheckpointCleanup(CheckpointConfig.ExternalizedCheckpointCleanup.RETAIN\_ON\_CANCELLATION);


        SourceFunction<String> sqlServerSource = SqlServerSource.<String>builder()
                .hostname("localhost")
                .port(1433)
                .username("SA")
                .password("")
                .database("test")
                .tableList("dbo.t\_info")
                .startupOptions(StartupOptions.initial())
                .debeziumProperties(getDebeziumProperties())
                .deserializer(new CustomerDeserializationSchemaSqlserver())
                .build();

        DataStreamSource<String> dataStreamSource = env.addSource(sqlServerSource, "\_transaction\_log\_source");
        dataStreamSource.print().setParallelism(1);
        env.execute("sqlserver-cdc-test");

    }


        public static Properties getDebeziumProperties() {
        Properties properties = new Properties();
        properties.put("converters", "sqlserverDebeziumConverter");
        properties.put("sqlserverDebeziumConverter.type", "SqlserverDebeziumConverter");
        properties.put("sqlserverDebeziumConverter.database.type", "sqlserver");
        // 自定义格式，可选
        properties.put("sqlserverDebeziumConverter.format.datetime", "yyyy-MM-dd HH:mm:ss");
        properties.put("sqlserverDebeziumConverter.format.date", "yyyy-MM-dd");
        properties.put("sqlserverDebeziumConverter.format.time", "HH:mm:ss");
        return properties;
    }

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51

2.2 自定义Sqlserver反序列化格式：

Flink-CDC底层技术为debezium，它捕获到Sqlserver数据变更(CRUD)的数据格式如下：

#初始化
Struct{after=Struct{id=1,order_date=2024-01-30,purchaser=1,quantity=100,product_id=1},source=Struct{version=1.9.7.Final,connector=sqlserver,name=sqlserver_transaction_log_source,ts_ms=1706574924473,snapshot=true,db=zeus,schema=dbo,table=orders,commit_lsn=0000002b:00002280:0003},op=r,ts_ms=1706603724432}

#新增
Struct{after=Struct{id=12,order_date=2024-01-11,purchaser=6,quantity=233,product_id=63},source=Struct{version=1.9.7.Final,connector=sqlserver,name=sqlserver_transaction_log_source,ts_ms=1706603786187,db=zeus,schema=dbo,table=orders,change_lsn=0000002b:00002480:0002,commit_lsn=0000002b:00002480:0003,event_serial_no=1},op=c,ts_ms=1706603788461}


#更新
Struct{before=Struct{id=12,order_date=2024-01-11,purchaser=6,quantity=233,product_id=63},after=Struct{id=12,order_date=2024-01-11,purchaser=8,quantity=233,product_id=63},source=Struct{version=1.9.7.Final,connector=sqlserver,name=sqlserver_transaction_log_source,ts_ms=1706603845603,db=zeus,schema=dbo,table=orders,change_lsn=0000002b:00002500:0002,commit_lsn=0000002b:00002500:0003,event_serial_no=2},op=u,ts_ms=1706603850134}


#删除
Struct{before=Struct{id=11,order_date=2024-01-11,purchaser=6,quantity=233,product_id=63},source=Struct{version=1.9.7.Final,connector=sqlserver,name=sqlserver_transaction_log_source,ts_ms=1706603973023,db=zeus,schema=dbo,table=orders,change_lsn=0000002b:000025e8:0002,commit_lsn=0000002b:000025e8:0005,event_serial_no=1},op=d,ts_ms=1706603973859}

1
2
3
4
5
6
7
8
9
10
11
12
13
14

因此，可以根据自己需要自定义反序列化格式，将数据按照标准统一数据输出，下面是我自定义的格式，供大家参考：

import com.alibaba.fastjson2.JSON;
import com.alibaba.fastjson2.JSONObject;
import com.alibaba.fastjson2.JSONWriter;
import com.ververica.cdc.debezium.DebeziumDeserializationSchema;
import io.debezium.data.Envelope;
import org.apache.flink.api.common.typeinfo.BasicTypeInfo;
import org.apache.flink.api.common.typeinfo.TypeInformation;
import org.apache.flink.util.Collector;
import org.apache.kafka.connect.data.Field;
import org.apache.kafka.connect.data.Schema;
import org.apache.kafka.connect.data.Struct;
import org.apache.kafka.connect.source.SourceRecord;

import java.util.HashMap;
import java.util.Map;

public class CustomerDeserializationSchemaSqlserver implements DebeziumDeserializationSchema<String> {

    private static final long serialVersionUID = -1L;


    @Override
    public void deserialize(SourceRecord sourceRecord, Collector collector) {
        Map<String, Object> resultMap = new HashMap<>();
        String topic = sourceRecord.topic();
        String[] split = topic.split("[.]");
        String database = split[1];
        String table = split[2];
        resultMap.put("db", database);
        resultMap.put("tableName", table);
        //获取操作类型
        Envelope.Operation operation = Envelope.operationFor(sourceRecord);
        //获取数据本身
        Struct struct = (Struct) sourceRecord.value();
        Struct after = struct.getStruct("after");
        Struct before = struct.getStruct("before");
        String op = operation.name();
        resultMap.put("op", op);

        //新增,更新或者初始化
        if (op.equals(Envelope.Operation.CREATE.name()) || op.equals(Envelope.Operation.READ.name()) || op.equals(Envelope.Operation.UPDATE.name())) {
            JSONObject afterJson = new JSONObject();
            if (after != null) {
                Schema schema = after.schema();
                for (Field field : schema.fields()) {
                    afterJson.put(field.name(), after.get(field.name()));
                }
                resultMap.put("after", afterJson);
            }
        }

        if (op.equals(Envelope.Operation.DELETE.name())) {
            JSONObject beforeJson = new JSONObject();
            if (before != null) {
                Schema schema = before.schema();
                for (Field field : schema.fields()) {
                    beforeJson.put(field.name(), before.get(field.name()));
                }
                resultMap.put("before", beforeJson);
            }
        }

        collector.collect(JSON.toJSONString(resultMap, JSONWriter.Feature.FieldBased, JSONWriter.Feature.LargeObject));

    }

    @Override
    public TypeInformation<String> getProducedType() {
        return BasicTypeInfo.STRING\_TYPE\_INFO;
    }

}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73

2.3 自定义日期格式转换器

debezium会将日期转为5位数字，日期时间转为13位的数字，因此我们需要根据Sqlserver的日期类型转换成标准的时期或者时间格式。Sqlserver的日期类型主要包含以下几种：

import io.debezium.spi.converter.CustomConverter;
import io.debezium.spi.converter.RelationalColumn;
import org.apache.kafka.connect.data.SchemaBuilder;
import java.time.ZoneOffset;
import java.time.format.DateTimeFormatter;
import java.util.Properties;

@Sl4j
public class SqlserverDebeziumConverter implements CustomConverter<SchemaBuilder, RelationalColumn> {



    private static final String DATE\_FORMAT = "yyyy-MM-dd";
    private static final String TIME\_FORMAT = "HH:mm:ss";
    private static final String DATETIME\_FORMAT = "yyyy-MM-dd HH:mm:ss";
    private DateTimeFormatter dateFormatter;
    private DateTimeFormatter timeFormatter;
    private DateTimeFormatter datetimeFormatter;
    private SchemaBuilder schemaBuilder;
    private String databaseType;
    private String schemaNamePrefix;


    @Override
    public void configure(Properties properties) {
        // 必填参数：database.type，只支持sqlserver
        this.databaseType = properties.getProperty("database.type");
        // 如果未设置，或者设置的不是mysql、sqlserver，则抛出异常。
        if (this.databaseType == null || !this.databaseType.equals("sqlserver"))) {
            throw new IllegalArgumentException("database.type 必须设置为'sqlserver'");
        }
        // 选填参数：format.date、format.time、format.datetime。获取时间格式化的格式
        String dateFormat = properties.getProperty("format.date", DATE\_FORMAT);
        String timeFormat = properties.getProperty("format.time", TIME\_FORMAT);
        String datetimeFormat = properties.getProperty("format.datetime", DATETIME\_FORMAT);
        // 获取自身类的包名+数据库类型为默认schema.name
        String className = this.getClass().getName();
        // 查看是否设置schema.name.prefix
        this.schemaNamePrefix = properties.getProperty("schema.name.prefix", className + "." + this.databaseType);
        // 初始化时间格式化器
        dateFormatter = DateTimeFormatter.ofPattern(dateFormat);
        timeFormatter = DateTimeFormatter.ofPattern(timeFormat);
        datetimeFormatter = DateTimeFormatter.ofPattern(datetimeFormat);

    }

    // sqlserver的转换器
    public void registerSqlserverConverter(String columnType, ConverterRegistration<SchemaBuilder> converterRegistration) {
        String schemaName = this.schemaNamePrefix + "." + columnType.toLowerCase();
        schemaBuilder = SchemaBuilder.string().name(schemaName);
        switch (columnType) {
            case "DATE":
                converterRegistration.register(schemaBuilder, value -> {
                    if (value == null) {
                        return null;
                    } else if (value instanceof java.sql.Date) {
                        return dateFormatter.format(((java.sql.Date) value).toLocalDate());
                    } else {
                        return this.failConvert(value, schemaName);
                    }
